Forged Fittings Specifications
Forged fittings are high-strength components used to connect pipes in piping systems, typically in high-pressure and high-temperature environments. Made by shaping metal under high pressure, they offer superior mechanical properties and durability. Common types include elbows, tees, couplings, unions, plugs, and bushings. These fittings are available in socket weld and threaded ends, complying with standards like ASME B16.11. Forged fittings are widely used in industries such as oil and gas, chemical processing, power generation, and shipbuilding for reliable, leak-free connections.
Stainless and Duplex Steel
| Range | 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS |
|---|---|
| Form | Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap |
| Stainless Steel | ASTM / ASME SA 182 F 304, 304L, 304H, 309H, 310H, 316, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H |
| Duplex Steel | ASTM / ASME SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61 |
Carbon & Alloy Steel
| Range | 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS |
|---|---|
| Form | Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap |
| Carbon Steel | ASTM / ASME A105, ASTM / ASME A350 LF2 |
| Alloy Steel | ASTM / ASME A182 GR F5, F9, F11, F12, F22, F91 |
Nickel & Copper Alloy
| Range | 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS |
|---|---|
| Form | Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap |
| Nickel Alloy |
ASTM / ASME SB 564 UNS 2200 (Nickel 200), UNS 4400 (Monel 400), UNS 8825 (Inconel 825), UNS 6600 (Inconel 600), UNS 6601 (Inconel 601), UNS 6625 (Inconel 625), UNS 10276 (Hastelloy C276); ASTM / ASME SB 160 UNS 2201 (Nickel 201); ASTM / ASME SB 472 UNS 8020 (Alloy 20 / 20 CB 3) |
| Copper Alloy |
ASTM / ASME SB 61 UNS NO. C92200; ASTM / ASME SB 62 UNS NO. C83600; ASTM / ASME SB 151 UNS NO. 70600, 71500, C70600 (Cu-Ni 90/10), C71500 (Cu-Ni 70/30); ASTM / ASME SB 152 UNS NO. C10100, C10200, C10300, C10800, C12000, C12200 |
Hastelloy
| Grades | Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000 |
|---|---|
| Types | Hastelloy Union, Hastelloy Coupling, Hastelloy Full Coupling, Hastelloy Cross, Hastelloy Forged Elbow, Hastelloy Hex Nipple, Hastelloy Plug, Hastelloy Bushing, Hastelloy Boss, Hastelloy Insert, Hastelloy Adapter, Hastelloy Socket, Hastelloy Forged Tee, Hastelloy Olets, Hastelloy Weldolet, Hastelloy Sockolet, Hastelloy Elbowlet, Hastelloy Thredolet, Hastelloy Nipolet, Hastelloy Latrolet, Hastelloy Sweepolet, Hastelloy Half Coupling |
Inconel
| Grades | Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750 |
|---|---|
| Standard | ASTM / ASME SB 564 |
| Types | Elbow - 90 Deg. & 45 Deg, Tee - Equal & Reducing, Union, Cross, Coupling - Full & Half, Socket Reducing, CAP, Plug - Hex & Square, Nipples (Hex / Reducing), Bushing, Sockolet, Weldolet, Thredolet, Elbolet, Nipolet |
Incoloy
| Grades | Incoloy 800, Incoloy 825, Incoloy 925, Incoloy A-286, Incoloy DS |
|---|---|
| Types | Union, Coupling, Full Coupling, Cross, Forged Elbow, Hex Nipple, Plug, Bushing, Boss, Insert, Adapter, Socket, Forged Tee, Olets, Weldolet, Sockolet, Elbowlet, Thredolet, Nipolet, Latrolet, Sweepolet, Half Coupling |
Monel
| Grades | Monel 400, Monel K500 |
|---|---|
| Types | Elbows, Equal/Unequal Tees, Concentric/Eccentric Reducers, Full/Half Couplings, Reducing Couplings, Caps, Cross, Unions, Hex/Reducing/Flash Bushings, Plugs, Nipples, Swage Nipples, Reducer Inserts, Boss, Laterals, Street Elbows, Outlets/Branch Connections (Weldolets, Thredolets, Sockolets, Flexolets, Latrolets, Elbolets, Sweepolets, Insert Weldolets, Nippolets, Brazolets, Coupolets) |
Titanium
| Grades | Grade 1, Grade 2, Grade 3, Grade 4, Grade 5, Grade 7, Grade 9, Grade 23 |
|---|---|
| Size | 1/2” NB to 4” NB |
| Types | Titanium Union, Titanium Coupling, Titanium Full Coupling, Titanium Cross, Titanium Forged Elbow, Titanium Hex Nipple, Titanium Plug, Titanium Bushing, Titanium Boss, Titanium Insert, Titanium Adapter, Titanium Socket, Titanium Forged Tee, Titanium Olets, Titanium Weldolet, Titanium Sockolet, Titanium Elbowlet, Titanium Thredolet, Titanium Nipolet, Titanium Latrolet, Titanium Sweepolet, Titanium Half Coupling |
Tantalum
| Specifications | ASTM B363, ASTM B16.9 Titanium pipe fittings |
|---|---|
| Material | Titanium Gr1, Gr2, Gr5, etc. |
| Product | Elbow, Tee, Stud End, Reducer |
| Elbow Type | 45 Deg Elbow, 90 Deg Elbow, 180 Deg Elbow |
| Tee Type | Straight Tee, Reducing Outlet Tee |
